Wide-format accent and halo tray. Covers 1.7–1.9 mm rounds on a 30 × 85 grid of 2,550 pockets, and takes 1.5–1.6 mm too — so one tray spans the whole 503B nozzle range. Handy when a design mixes halo accents with pavé fill. Order it if your machine takes the wide-format holder. Same-day dispatch from Mumbai and Rajkot.
Talk to our team about specifications, a demo, or installation.
Security policy
Delivery policy
Return policy
The SSMWT-03 is the most flexible tray in the wide-format ladder. Its pockets are cut for the 1.7–1.9 mm accent and halo sizes that frame a centre stone, but they seat 1.5–1.6 mm cleanly as well — so a single tray covers the entire working range of the 503B nozzle. On a floor where one design mixes a halo band with pavé fill, that is one changeover you stop making.
At this size a stone is big enough to be visibly wrong. A 1.8 mm accent that sits proud or drops low reads immediately in the finished halo, and unlike micro-pavé there is no crowd to hide it in. The pocket depth here puts the girdle exactly where the 503B expects it, so placement height stays constant across all 2,550 positions and across repeat runs of the same design.
| Parameter | Specification |
|---|---|
| Product Code | SSMWT-03 |
| Diamond Size Range | 1.7–1.8–1.9 mm primary; 1.5–1.6 mm backwards compatible |
| Sorting Grid | 30 × 85 matrix (wide-format layout) |
| Total Stone Capacity | 2,550 diamonds per full load |
| Pocket Spacing Geometry | (X-2) × (Y2) × (Z10) calibrated pitch |
| Tray Number | 15-16 (for 1.5–1.6 mm) / 17-18-19 (for 1.7–1.9 mm) |
| Recommended Nozzle | SSMN-04 (503B) |
| Compatible Machines | Semsons Tech Mini Pro, Pro Series, Pro Plus and Double Head 8 Nozzle wax setting machines |
| Stone Types Supported | Natural diamond, lab-grown diamond (CVD/HPHT), CZ, synthetic rounds |
| Compact Alternative | DSSMT-03 (40 × 80 grid, 3,200 stones) |
| Dispatch | Same-day from our Mumbai & Rajkot warehouses |
The wide-format ladder covers the same five stone bands as the compact one. Find your stone size below and you have your tray and your nozzle. This tray is highlighted.
| Tray Code | Stone Size Band | Grid | Capacity | Nozzle |
|---|---|---|---|---|
| DSSMT-01L | 0.8 – 1.2 mm | 30 × 85 | 2,550 | 502 / 502B |
| SSMWT-02 | 1.3 – 1.6 mm | 30 × 85 | 2,550 | 503 / 503B |
| SSMWT-03 | 1.7 – 1.9 mm | 30 × 85 | 2,550 | 503B ◀ this product |
| SSMWT-04 | 2.0 – 2.5 mm | 15 × 49 | 735 | 504 |
| SSMWT-05 | 2.5 – 3.0 mm | 15 × 49 | 735 | 504 |
Wide-format and compact trays cover the same stone bands; what differs is the footprint of the tray itself. Which one you need is decided by the tray holder on your machine, not by preference. If you are ordering a wide-format tray for the first time, send us your machine model and we will confirm the fit before dispatch. The compact equivalent of this tray is DSSMT-03 (40 × 80 grid, 3,200 stones).
Support the tray along its length when you carry it — long trays flex, and flex means inconsistent pocket depth. Invert to empty, blow out with clean dry air, store flat and unstacked. Check pocket rims under a loupe every few hundred hours; a sharp, bright rim is what keeps a 1.9 mm round sitting square rather than tilted.
Match three things and you cannot go wrong: the stone size band (1.7 – 1.9 mm (also takes 1.5 – 1.6 mm) for this tray), the nozzle already fitted to your machine (503B), and your machine model. If any of the three does not match, order the tray next to it on the ladder above instead — or send us your machine model and stone size and we will confirm it for you before dispatch.
Yes — this tray is dimensioned for Semsons Tech Mini Pro, Pro Series, Pro Plus and Double Head 8 Nozzle wax setting machines. It is not a generic import tray cut to a nominal size; the pocket pitch is machined to the coordinate map our setters actually use, which is what keeps pickup accurate from the first stone to the last.
Stay inside the published band. Stones under the band sit too deep for the nozzle to seat against, and oversized stones bridge across the pocket mouth and get knocked aside on the next pass. Both show up as skipped positions in the wax, which you only discover after casting.
Most production floors keep one tray per size band they actually run, plus a spare of their highest-volume band. On double-station and double-head machines a second tray removes the reload pause entirely — you pre-fill one while the other is on the bed.
Empty it by inversion over a sorting pad rather than brushing stones across the pockets, blow out dust with clean dry air, and store it flat. Never stack loaded trays, and keep solvents off the pocket faces — anything that etches or scores a pocket changes its depth, and depth is what the nozzle is calibrated against.
No. The pockets are cut for the larger band and smaller stones seat lower within the same geometry, which the 503B is calibrated to handle. What you gain is one tray instead of two across a common design range.
The SSMWT-03 ships same-day from our Mumbai and Rajkot warehouses, across India and to the 34+ countries we export to. Buying a full set of wide-format SSMWT trays to cover your whole size range, or restocking several of one band for a multi-machine floor? Ask for set pricing rather than ordering them one at a time.
Semsons Tech has supplied the Indian jewellery trade since 1978, with 16+ stores and warehouses, 450+ dealers and 40+ distributors behind every consumable we sell.
Not sure which part fits your machine? Send us your machine model and the stone size you are running, and we will confirm the correct item before we dispatch — so you never pay to find out it was the wrong one.
