Semsons Tech

Vacuum Wax Injectors D4

Request a quote

Pricing depends on configuration, quantity and your requirements.

D4 Intelligent Chip Vacuum Wax Injector by Semsons Tech is a premium semi-automatic wax injection machine designed for jewellery manufacturers handling multiple product lines. Its intelligent chip memory system stores up to 990 injection recipes and automatically loads parameters for compatible molds, reducing setup time and operator errors. Features include vacuum-assisted injection, a flexible 3D fixture, one-key operation mode, and a wax-level alarm for improved process control. Compatible with Ferris, GRS, and SRS injection waxes for gold, silver, and platinum casting workflows. Ideal for production environments requiring consistent wax pattern quality across a wide product range. Includes installation, training, warranty, and technical support.

Share your requirement and our team will send you pricing, availability and a quotation.

The Premium Intelligent Chip Wax Injector - 990-Parameter Memory System for Chain-Retail and Multi-Product-Line Operations

Chain-retail wholesale and large-volume designer operations face a unique workflow challenge: producing 100-500+ different product lines requires equally diverse rubber mold inventory, and each mold needs specific injection parameters (temperature, pressure, vacuum time, injection time, hold time). Traditional vacuum wax injectors with 10-20 slot memory functions cannot manage this diversity - operators end up manually setting parameters per mold, creating parameter-input errors and quality variability. The D4 Intelligent Chip Vacuum Wax Injector addresses this scaling problem through chip-based mold identification - each rubber mold equipped with intelligent chip; chip stores mold-specific parameters; machine reads chip when mold positioned and automatically loads parameters; no manual parameter entry required. 990-recipe storage capacity on the machine chip system supports operations with extensive mold libraries. One-key mode for quick injection when chip-less molds are used. 3D fixture with flexible movement supports diverse mold geometries. Vacuum chamber wax level alarm prevents wax from blocking vacuum gauge and three-way ball valve during operation.

For 48 years, Semsons Tech has supplied the Indian jewellery manufacturing industry. The D4 is the production-default for chain-retail wholesale operations producing 100-500+ product lines, large designer ateliers managing diverse commission and brand-line production, lab-grown diamond brand mount operations with multiple style variants, CMT operations requiring chip-driven parameter management, and casting service bureaus processing client orders across diverse mold types.

Core Engineering Advantages

  • Intelligent Chip Mold Identification - 990-Parameter Memory: The decisive automation feature. Each rubber mold equipped with intelligent chip storing mold-specific parameters (injection pressure, vacuum time, injection time, hold time, temperature). Machine reads chip automatically when mold positioned at injection nozzle; parameters loaded into active cycle without operator input. 990-recipe storage capacity supports operations with extensive mold libraries - chain-retail wholesale operations producing 100-500+ product lines manage complete recipe inventory. Production economics: eliminates parameter-input errors that create defective wax patterns; supports consistent quality across operator experience levels; reduces operator training time for multi-mold workflow.
  • One-Key Mode for Chip-less Molds: Flexible workflow accommodation - operations using legacy molds without chips can use one-key mode where injection parameters are set manually and machine executes with single-button-press initiation. Hybrid workflow support: operations transitioning from legacy molds to chip-equipped molds maintain production continuity during transition; new molds added to chip system progressively without workflow disruption.
  • 3D Fixture with Flexible Movement and Convenient Adjustment: Mold positioning system supports diverse mold geometries. Workflow advantage: operations producing molds with varying dimensions (ring molds, pendant molds, bracelet molds, earring molds - each with different dimensions and orientations) benefit from flexible fixture adjustment without dedicated fixtures per mold type. 3D adjustment covers vertical, horizontal, and angular positioning supporting comprehensive mold range.
  • Vacuum Chamber Wax Level Alarm: Production-grade safety and reliability feature. Sensor detects wax level rising into vacuum chamber (a common failure mode when injection parameters are misconfigured); alarm prevents wax from blocking the vacuum gauge and three-way ball valve. Why this matters: wax blockage in vacuum components requires extended machine teardown for cleaning; alarm prevents this maintenance-intensive failure mode supporting operational continuity. Critical for high-volume operations where machine downtime creates significant production disruption.
  • Low-Pressure Long-Range Wax Injection: Engineering signature delivers wax to mold cavity at low pressure across long-range injection path. Production advantages: (1) Reduced rubber mold stress at lower injection pressure extends mold operational life. (2) Better detail capture in complex mold geometry - gentle pressure flow reaches fine detail without forcing wax past obstructions. (3) Lower power consumption for sustained production duty. (4) Supports complex designer pieces where high-pressure injection damages intricate mold detail.
  • Dual Digital Temperature Control with ±0.2°C Accuracy: Separate digital thermostats for wax pot and injection nozzle deliver precision temperature control independent at each stage. Operating range: 40-100°C supporting standard injection wax (65-75°C) and specialty white wax (90-100°C).
  • Vacuum Chamber + Programmable Injection Timers: Vacuum chamber evacuates rubber mold cavity before wax flows - bubble-free patterns on complex multi-stone settings and filigree. Programmable injection, vacuum, and hold timers support reproducible cycle execution.

Technical Specifications

Technical ParameterSpecification
ModelD4 - Intelligent Chip Vacuum Wax Injector (premium semi-automatic with chip memory system)
TechnologyIntelligent chip wax injection with dual temperature control + vacuum + 3D fixture + 990-parameter memory
Memory SystemIntelligent chip per mold (auto-loads parameters) + 990-parameter storage capacity on machine
One-Key ModeQuick injection for chip-less molds; manual parameter setting with single-button cycle activation
Fixture System3D fixture with flexible movement and convenient adjustment; supports diverse mold geometries
Vacuum Chamber AlarmWax level alarm prevents wax blocking vacuum gauge and three-way ball valve
Injection PressureLow-pressure long-range injection; programmable per mold via chip
Temperature ControlDual digital thermostats (separate for wax pot and injection nozzle); ±0.2°C accuracy
Temperature Range40-100°C (supports standard injection wax 65-75°C + specialty/white wax 90-100°C)
Vacuum SystemVacuum chamber evacuates mold cavity before injection; programmable vacuum time
Wax Tank Capacity3-5kg (variant-dependent) - supports 6-10 hour autonomy
Auto-ClampPneumatic auto-clamp with programmable clamp force per mold chip
Programmable TimersInjection time, vacuum time, hold time - all programmable per mold via chip
Standby Timer1-99 hour programmable heating schedule (pre-warm before operator arrival)
Power600-800W
Power Supply220-240V single-phase 50Hz (Indian workshops)
Compressed Air SupplyExternal air compressor required (typical 6-8 bar workshop supply)
Compatible Wax VariantsAll standard injection wax (Ferris Magna-Ject, GRS, SRS, Castaldo) + specialty harder/white waxes
Compatible Casting Metals (Downstream)Gold (10K-22K - all colors), silver (sterling + 925), platinum, palladium, brass, copper
PriceQuoted per configuration
Intelligent Chip SupplySold separately for mold tagging; multi-pack bundle pricing
Warranty1-year manufacturer warranty with free technical support and spare parts
InstallationOn-site installation and operator training by Semsons authorized technician
Companion ProductsIntelligent chips (sold separately), Wax Beads, Vulcanizer, air compressor + vacuum pump
Service NetworkOn-site service across 16+ Indian cities via 450+ dealer network
Export MarketsUAE, USA, Canada, Hong Kong, Bangkok, Saudi Arabia, UK + 25 more
SupplierSemsons Tech - JMAIIE Excellence Awards winner, Since 1978

D4 vs T-Series vs DVWI-1 - Which Should You Choose?

  • Choose DVWI-1: tabletop entry tier; 10-slot memory.
  • Choose T4: workshop standard; no chip system; manual parameter management.
  • Choose T4A: high-capacity 5L; 15-20 slot memory.
  • Choose D4: chain-retail wholesale + multi-product-line operations producing 100-500+ product lines; intelligent chip system; 990-parameter capacity; eliminates parameter-input errors.
  • Upgrade to Automatic Robotic: for high-volume factories that want automated mould handling and a stored recipe for every mould.

Pricing, Installation & Support

Indian market pricing is quoted per configuration. Intelligent chips sold separately for mold tagging - multi-pack bundle pricing. Complete starter bundle pricing combining D4 + initial intelligent chip supply (matched to current mold inventory) + Wax Beads (Ferris/GRS/SRS premium injection wax - 10-15kg initial supply) + air compressor + vacuum pump + operator training. On-site installation by Semsons authorized technician - includes electrical and pneumatic supply integration, chip system configuration, initial mold tagging with parameter optimisation, first-cycle validation. Comprehensive operator training covering machine operation, intelligent chip programming, parameter optimisation through trial cycles, one-key mode for chip-less molds, troubleshooting, and complete workflow integration. 1-year manufacturer warranty with free technical support and spare parts. Comprehensive spare parts supply with. Dealer-network service across 16+ Indian cities. Wholesale enquiries on +91 80823 38010.

Why Buy D4 from Semsons Tech

Semsons Tech is a JMAIIE Excellence Awards-winning manufacturer and supplier with 48 years in jewellery equipment, 16+ stores and warehouses, 40+ distributors, 450+ dealers, exports to 34+ countries. Semsons supplies the D4 with intelligent chip mold identification with 990-parameter memory capacity, one-key mode for chip-less mold accommodation, 3D fixture with flexible movement, vacuum chamber wax level alarm preventing maintenance failures, low-pressure long-range injection for premium pattern quality, dual digital temperature control ±0.2°C accuracy, vacuum chamber with programmable timer, pneumatic auto-clamp with chip-driven programmable force, standby timer 1-99 hours, ongoing intelligent chip supply with, on-site installation and comprehensive operator training, 1-year warranty, comprehensive spare parts supply, and complete workflow integration consultation. For chain-retail wholesale and multi-product-line operations where parameter-input errors create significant quality variability across diverse mold inventory, intelligent chip identification fundamentally transforms production workflow management. Where Quality Speaks For Us - Since 1978.

Order Your D4 Today

For pricing across configuration variants, complete starter bundle (D4 + intelligent chips + wax + compressor + vacuum pump + training), intelligent chip multi-pack bundle pricing for large-mold-inventory operations, complete workflow bundle pricing combining D4 with paired equipment (Wax Beads premium injection wax, Vulcanizer for rubber mold creation, downstream Investment Powder Mixer + Burnout Furnace + Vacuum Casting Machine + Tree Cutting Machine + complete finishing equipment), international export, or technical consultation, WhatsApp our sales desk on +91 98216 12340 or wholesale on +91 80823 38010. Pair with the complete Semsons jewellery production workflow ecosystem across upstream Wax Beads + Vulcanizer, casting (Investment Powder Mixer, Burnout Furnace, Induction Melters, Vacuum Casting Machine, Water Jet Machine, Tree Cutting Machine), finishing (Foredom Motors, Polishing Machines, Electro Polishing Machine, Tumbler Polishing Machine, Filing Table), welding (Earring Post Welding Machine), cleaning (Ultrasonic Cleaner + Diamond Bright Solutions), and plating (Rhodium Plating Machine + plating solution ranges).
